This dimmer controller is compatible with Bromic Platinum or Tungsten electric patio heaters. It allows you to instantly and precisely adjust the heat output down to 1% increments for one, two or five channel inputs - each able to control up to 6,000 watts of power. The five channel version includes a handy expansion board for ethernet integration or 0-10V control for automated home or business integrations. It connects with the Bromic Heating App through your WiFi system or up to 30 feet via Bluetooth.
Specifications
| Specs |
1 Channel |
2 Channels |
5 Channels |
| Voltage-Max Capacity Per Channel | 208-277V – 6kW | 208-277V – 6kW | 3N-220/380V – 6kW
3N-230/400V – 6kW
3N-240/415V – 6kW
3N-277/480V – 6kW
3- 120/208V – 6kW |
| Operating Temperature Range | -4°F to +86°F | -4°F to +86°F | -4°F to +86°F |
| Non-Operating Temperature Range | -22°F to +158°F | -22°F to +158°F | -22°F to +158°F |
| Protection Rating | IP54 | IP54 | IP54 |
| WiFi Connectivity | 2.4GHZ | 2.4GHZ | 2.4GHZ |
Features
- Compatible with Bromic Platinum and Tungsten electric patio heaters
- Expansion board accessory included with the 5 Channel model
- Connect to Bromic Heating App wirelessly or via Bluetooth up to 30 feet for on/off control
- Schedule & timer settings
- Integrated voice control with Google Home & Amazon Alexa
| MANUFACTURER | Bromic |
|---|
| MODEL | BRO-BH3130061-63 |
|---|
| DIMENSION | 1 & 2 CH 8 W x 6.4 D x 11.4 H | 5 CH 19.7 W x 10 D x 13.4 H |
|---|
