The Woodline Mistral Center Pole Umbrella provides shade for individual dining tables, poolside loungers and smaller residential patios. Its anodized aluminum pole and ribs coordinate with metal furniture without introducing a contrasting wood finish. Glass-reinforced composite hubs and stainless steel fittings support the canopy assembly.
Choose from two hexagonal sizes and two square options, all with a 1.5" diameter pole. The 6'7" square suits compact dining settings where a larger canopy would overhang nearby seating or circulation space. Square shapes follow linear furniture arrangements, while hexagonal canopies complement round tables. Check canopy dimensions against the full seating area, including chairs pulled out from the table.
Mistral Canopy Sizes & Shapes
| Shape | Size | Pole Diameter |
|---|---|---|
| Hexagon | 8'11" | 1.5" |
| Hexagon | 9'10" | 1.5" |
| Square | 6'7" | 1.5" |
| Square | 8'2" | 1.5" |
A built-in pulley system opens the canopy, and a stainless steel pin secures it in position. The attached chain keeps the pin with the frame during opening and closing, so there's no loose component to set aside.
The Symphony solution-dyed acrylic canopy comes in a choice of colors to coordinate with upholstery and exterior finishes. Mistral's smart attachment system allows the fabric to be removed for cleaning or replacement. For properties maintaining several umbrellas, canopy care can be handled separately from the frames. A protective cover is included.
Choose a freestanding base when furniture layouts may change or a fixed mount for an established shade position. The wheeled square metal option helps with repositioning a closed umbrella as tables or loungers are rearranged.
Mistral Umbrella Base & Mounting Options
| Size | Canopy Shape | Suggested Freestanding Bases |
|---|---|---|
| 8'11" | Hexagon | Concrete base, 20" round metal base or wheeled 24" square metal base |
| 9'10" | Hexagon | Concrete base, 20" round metal base or wheeled 24" square metal base |
| 6'7" | Square | Concrete base, 20" round metal base or wheeled 24" square metal base |
| 8'2" | Square | Concrete base, 20" round metal base or wheeled 24" square metal base |
Deck, concrete and in-ground mounts keep a freestanding base out of the furniture layout. Select the mounting hardware and receiver tube specified for Mistral. For through-table installations, check the umbrella-hole diameter and closing clearance against the furniture.
Base and mounting options are sold separately. Suggested bases follow Woodline's configuration-specific guidance. A table does not replace the need for appropriate umbrella support.
Woodline classifies Mistral for moderate-breeze applications. Consider site exposure and the selected support when planning its position. Close and secure the umbrella when winds increase or whenever it's unattended.
Features
- Built-in pulley lift system
- Anodized aluminum pole and ribs
- Glass-reinforced composite hubs
- Stainless steel fittings, retaining pin and chain
- Smart canopy attachment system
- Symphony solution-dyed acrylic canopy
- Protective cover included
| MODEL | MISTRAL |
|---|---|
| MANUFACTURER | Woodline |
| STYLE | Contemporary,Minimalist |
| DIMENSION | 6'7-10W x 6'7-10D x 8'3H |
| MATERIAL | Aluminum,Solution-Dyed Acrylic |
| SPEC SHEET | Mistral Specifications |
|---|
- Subjective Returns: No
- Restocking Fees: N/A
- Claim Timeframe: Woodline Shade Solutions must be notified of damaged items within 5 business days of delivery.
Customers must sign for the delivery and retain all packing materials, boxes, tubes, wrapping, etc until the merchandise is checked and no damages are evident. If the customer is unable to open the boxes and inspect at the time of delivery, please make sure that they do not sign their name on the Bill of Lading but write “PENDING INSPECTION” instead.
